Publication 2098-RM003A-EN-P October 2001
2-62 Command Reference
Motor Commands Encoder Lines / Revolution
Maximum Rotary Speed
Format: :aa037fddddcc
Parameter
Code: 0x037
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x04 = Data Below Minimum
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dddd Encoder lines per revolution.
Minimum
Value: 100
Maximum
Value: 64000
Default: 2000
Format: :aa038fddddcc
Parameter
Code: 0x038
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x04 = Data Below Minimum
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dddd Maximum speed of a rotary motor, in units of RPM.
Minimum
Value: 300
Maximum
Value: 0x7FFF
Default: 3500
