Publication 2098-RM003A-EN-P October 2001
2-18 Command Reference
Frame Format
Drive Address
Format: :aa051fddcc
Parameter
Code: 0x051
Valid Function
Codes: 0x0 = Read Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dd Frame format code, where:
0x00 7 bits, Even parity, 1 Stop
0x01: 7 bits, Odd parity, 1 Stop
0x02: 8 bits, No parity, 1 Stop
0x03: 8 bits, Even parity, 1 Stop
0x04: 8 bits, Odd parity, 1 Stop
Minimum
Value: 0x00
Maximum
Value: 0x04
Default: 0x02
Format: :aa052fddcc
Parameter
Code: 0x052
Valid Function
Codes: 0x0 = Read Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dd Drive address for serial communications.
Minimum
Value: 0
Maximum
Value: 253
Default: 0x00
