Publication 2098-RM003A-EN-P October 2001
Command Reference 2-59
Home Sensor Polarity
Homing Creep Velocity
Format: :aa0CBfddcc
Parameter
Code: 0x0CB
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dd Polarity of the home sensor, where:
0x00: Inactive-to-active transition
0x01: Active-to-inactive transition
Minimum
Value: 0x00
Maximum
Value: 0x01
Default: 0x00
Format: :aa0CCfddddddddcc
Parameter
Code: 0x0CC
Valid Function
Codes: 0x0 = Read Working Value
0x1 = Write Working Value
0x2 = Read Non-Volatile Value
0x3 = Write Non-Volatile and Working Values
0x4 = Copy Non-Volatile Value to Working Value
0x5 = Copy Working Value to Non-Volatile Value
0x6 = Read Default Value
0x7 = Copy Default Value to Non-Volatile and Working Values
0x8 = Read Minimum Value
0x9 = Read Maximum Value
Valid Exception
Codes: 0x03 = EEPROM Write Error
0x04 = Data Below Minimum
0x05 = Data Above Maximum
0x08 = Invalid Function Code
Data Fields: dddddddd Homing creep velocity, in units of counts/second.
Minimum
Value: 0x00000001
Maximum
Value: 0x7FFFFFFF
Default: 10,000
