background image

Publication 1794-UM063A-EN-P - March 2006

2-20 Configurable FLEX I/O Analog Module Features

Secondary Master Enable (SME) and Primary Master Inhibit (PMI)

These two bits control a few module internal functions individually for
channels 0 to 7.

HART Status Indicators

When this bit is set, the indicators are used for HART diagnostics. indicator
behavior changes to show communication on HART with each indicator
representing a HART loop. A flashing yellow indicator means that
communication is currently being processed while a solid yellow indicator
means that this device is in the transmitter list.

HART Status Inhibit

When this bit is set, the HART communication status is not shown in the
realtime data table to enable compatibility. The appropriate areas are cleared
with zeroes.

50 or 60 Hz Filter

The values are:

• 0 = 50 Hz (default)
• 1 = 60 Hz

Table 2.18 SME and PMI Values

Bits

(1)

1 (Default)

2

3

4

PMI

8, 9, 10, 11, 12,
13, 14, 15

0

0

1

1

SME

0, 1, 2, 3, 4, 5, 6, 7

0

1

0

1

HART Smooth Filter

Pulsed

On

Off

On

Rebuild

On

On

Off

Off

HART Read Back

On

On

Off

Off

Primary Master

On

On

Off

Off

Secondary Master

Off

On

Off

On

1

Where:
Ch0 - bits 0 and 8; Ch1 - bits 1 and 9; Ch2 - bits 2 and 10; Ch3 - bits 3 and 11;
Ch4 - bits 4 and 12; Ch5 - bits 5 and 13; Ch6 - bits 6 and 14; Ch7 - bits 7 and 15
