1

Publication 1794-UM063A-EN-P - March 2006

Appendix

E

Configure the 1794-IE8H Module in RSLogix
5000 Software Over the ControlNet Network

What This Appendix
Contains

This appendix provides the information needed to configure the 1794-IE8H
analog input module in RSLogix 5000 software over the ControlNet network
using version 13 or earlier and the generic profile.

Background Information

Make sure that your Comm-Format is set to Input Data - INT so that you can
set the output size to 0. In the FLEX generic profile, you need these sizes:

• Input - 8
• Output - 0
• Config - 2
• Status - 5

Adapter Name is what you named the ControlNet adapter when it was
originally created.

Slot is the position of the FLEX module in the rack, starting with zero.

IMPORTANT

HART commands will only work when the Data Format control
is configured for a 4 to 20 mA range. The default configuration
when using the generic profile is 0, which configures the
module for a 0 to 20 mA range. The filter cutoff defaults to 0 as
well, which is invalid. The filter cutoff must be set to a valid
value for the module to operate in any mode.
