Publication 1794-UM063A-EN-P - March 2006
E-8 Configure the 1794-IE8H Module in RSLogix 5000 Software Over the ControlNet Network
Overrange Alarm
Local Fault
Remote Fault
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[8].8
1
[Adapter Name]:[Slot]:I.Data[8].9
2
[Adapter Name]:[Slot]:I.Data[8].10
3
[Adapter Name]:[Slot]:I.Data[8].11
4
[Adapter Name]:[Slot]:I.Data[8].12
5
[Adapter Name]:[Slot]:I.Data[8].13
6
[Adapter Name]:[Slot]:I.Data[8].14
7
[Adapter Name]:[Slot]:I.Data[8].15
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[9].0
1
[Adapter Name]:[Slot]:I.Data[9].1
2
[Adapter Name]:[Slot]:I.Data[9].2
3
[Adapter Name]:[Slot]:I.Data[9].3
4
[Adapter Name]:[Slot]:I.Data[9].4
5
[Adapter Name]:[Slot]:I.Data[9].5
6
[Adapter Name]:[Slot]:I.Data[9].6
7
[Adapter Name]:[Slot]:I.Data[9].7
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[9].8
1
[Adapter Name]:[Slot]:I.Data[9].9
2
[Adapter Name]:[Slot]:I.Data[9].10
3
[Adapter Name]:[Slot]:I.Data[9].11
4
[Adapter Name]:[Slot]:I.Data[9].12
5
[Adapter Name]:[Slot]:I.Data[9].13
6
[Adapter Name]:[Slot]:I.Data[9].14
7
[Adapter Name]:[Slot]:I.Data[9].15
