Configure the 1794-IE8H Module in RSLogix 5000 Software Over the ControlNet Network E-7
Square Root Threshold
Input
Analog Input Data
Underrange Alarm
Bits
[Adapter Name]:[Slot]:C.Data[1].14
[Adapter Name]:[Slot]:C.Data[1].15
15
14
Range
0
0
Disabled
0
1
2%
1
0
5%
1
1
10%
Channel
Words
0
[Adapter Name]:[Slot]:I.Data[0]
1
[Adapter Name]:[Slot]:I.Data[1]
2
[Adapter Name]:[Slot]:I.Data[2]
3
[Adapter Name]:[Slot]:I.Data[3]
4
[Adapter Name]:[Slot]:I.Data[4]
5
[Adapter Name]:[Slot]:I.Data[5]
6
[Adapter Name]:[Slot]:I.Data[6]
7
[Adapter Name]:[Slot]:I.Data[7]
Channel
Bits
0
[Adapter Name]:[Slot]:I.Data[8].0
1
[Adapter Name]:[Slot]:I.Data[8].1
2
[Adapter Name]:[Slot]:I.Data[8].2
3
[Adapter Name]:[Slot]:I.Data[8].3
4
[Adapter Name]:[Slot]:I.Data[8].4
5
[Adapter Name]:[Slot]:I.Data[8].5
6
[Adapter Name]:[Slot]:I.Data[8].6
7
[Adapter Name]:[Slot]:I.Data[8].7
