Output, Analog fault state values, Digital output data global output data – Rockwell Automation 1794-OE8H FLEX I/O HART Analog Modules User Manual User Manual
Page 136
Publication 1794-UM063A-EN-P - March 2006
F-6 Configure the 1794-OE8H Module in RSLogix5000 Software Over the ControlNet Network
Analog Fault State Values
Output
Refer to the following tables for output information.
Digital Output Data
Global Output Data
The Global reset bit goes in bit
[Adapter Name]:[Slot]:O.Data[0].14.
Channel
Bits
0
[Adapter Name]:[Slot]:C.Data[3]
1
[Adapter Name]:[Slot]:C.Data[4]
2
[Adapter Name]:[Slot]:C.Data[5]
3
[Adapter Name]:[Slot]:C.Data[6]
4
[Adapter Name]:[Slot]:C.Data[7]
5
[Adapter Name]:[Slot]:C.Data[8]
6
[Adapter Name]:[Slot]:C.Data[9]
7
[Adapter Name]:[Slot]:C.Data[10]
Channel
Bits
0
[Adapter Name]:[Slot]:O.Data[0].0
1
[Adapter Name]:[Slot]:O.Data[0].1
2
[Adapter Name]:[Slot]:O.Data[0].2
3
[Adapter Name]:[Slot]:O.Data[0].3
4
[Adapter Name]:[Slot]:O.Data[0].4
5
[Adapter Name]:[Slot]:O.Data[0].5
6
[Adapter Name]:[Slot]:O.Data[0].6
7
[Adapter Name]:[Slot]:O.Data[0].7
