Publication 1794-UM063A-EN-P - March 2006
Configure the 1794-IE8H Module in RSLogix 5000 Software Over the ControlNet Network E-9
Diagnostic Status
Bits
[Adapter Name]:[Slot]:I.Data[10].0
[Adapter Name]:[Slot]:I.Data[10].1
[Adapter Name]:[Slot]:I.Data[10].2
[Adapter Name]:[Slot]:I.Data[10].3
Diagnostic Description Bit 3 Bit 2 Bit 1 Bit 0
Normal 0 0 0 0
Calibration Failure 0 0 0 1
Configuration Failure 0 0 1 0
Message Failure 0 0 1 1
Lead Break Detection 0 1 0 0
EEPROM Failure 0 1 0 1
RAM Failure 0 1 1 0
ROM Failure 0 1 1 1
Calculation Failure 1 0 0 0
Data Out of Range 1 0 1 1
