Configurable FLEX I/O
Analog Module Features

What This Chapter Contains

Read this chapter to familiarize yourself with configurable features on the
input and output analog modules.

HART configurable features described in this chapter include the following

For Information On

See Page

Select Your 1794-IE8H FLEX I/O Analog
Input Module’s Operating Features

2-2

Select Your 1794-OE8H FLEX I/O Analog
Output Module’s Operating Features

2-7

Understand Image Table Mapping and
Bit/Word Descriptions

2-12

Instance: Slot number (range from 1 to 8
with 1 being the I/O module closest to the
adapter

2-19

Table 2.1 Analog/Digital Configurable Features on the FLEX I/O Analog I/O Modules

1794-IE8H Input Module Features

1794-OE8H Output Module Features

Fault Mode

Output Enable

Remote Transmitter Error Up or Down

Module Fault State Mode

High Low Error Level

Local Fault Mode

Input Filter Cutoff

Digital Output

Data Format

Latch Retry Mode

Global Reset

Analog Digital State

Analog Fault State

Digital Fault State

Data Format

Fault Alarm
