Publication 1794-UM063A-EN-P - March 2006

Configurable FLEX I/O Analog Module Features 2-19

1794-IE8H and -OE8H
Extended Configuration
Data Table

The FLEX I/O HART modules are addressed by using an MSG or CIO
instruction. When using one of these instructions, configure it to the
following.

• Class: 0x7D
• Instance:

Slot number (range from 1 to 8 with 1 being the I/O

module closest to the adapter

• Attribute: 0x66
• Service: 0x0E for a get attribute single or 0x10 for a set attribute single

Also, configure the communication path to the target I/O module.

For a set attribute single, configure two words as defined in the Extended
Configuration Data Table to be sent to the I/O module.

For a get attribute single, two words configured as defined in the Extended
Configuration Data Table will be returned from the instruction.

Table 2.17 1794-IE8H and -OE8H Extended Configuration Data Table

Bit

15

14

13

12

11

10

09

08

07

06

05

04

03

02

01

00

Word

0

PMI
ch 7

PMI
ch 6

PMI

ch 5

PMI

ch 4

PMI

ch 3

PMI

ch 2

PMI

ch 1

PMI

ch 0

SME

ch 7

SME

ch 6

SME

ch 5

SME

ch 4

SME

ch 3

SME

ch 2

SME

ch 1

SME

ch 0

1

Reserved

HART Read Back Threshold

ch 4…7

HS

LED

HS

Inht

50/

60 Hz

HART Read Back Threshold

ch 0…3

Where:

ch = channel
PMI = Primary Master Inhibit
SME = Secondary Master Enable
HS LED = HART Status LEDs
HS Inht = HART Status Inhibit
