3–3

Connect the Adapter to the PROFIBUS DP Network

Publication 1794ĆUM057B-EN-P - November 2001

Line B cabling can support baudrates as high as 500k bits/s.

Cables

You need a shielded twisted pair cable for your cabling (bus
segments or drop cables). Any shielded twisted pair cables available
on the market can be used to connect your adapter to a PROFIBUS
network, however, bus segment cables must contain wire for data
ground and a cable braid shield. We recommend Sprecher+Schuh
cable as shown in the table below.

TĆjunction Connectors

You need t-junction connectors to connect your droplines to bus
segments. You can use any t-junctions available on the market,
however, we recommend Sprecher+Schuh connectors as shown in
the table below.

Termination Blocks

Termination blocks are only needed if the devices on the end of the
network do not have built-in terminating resistors. If you need to use
termination blocks, any termination blocks available on the market
can be used, however, we recommend Sprecher+Schuh termination
blocks as shown in the table below.

Bus Connector

Connect your adapter to the PROFIBUS DP network by attaching a
bus connector to the female 9 pin D-Sub connector on the front of
the module.

IMPORTANT

For detailed information on the topology and
cabling for line B, see the PROFIBUS Standard
(DIN 19245 Parts 1 & 3, Issue 1994).

Equipment

Type

Catalog Number

Part Number

Drop cable

Sprecher + Schuh

PTLĆ2, PTLĆ4, or PDCĆ10

87.890.282Ć10

TĆjunction connector

Sprecher + Schuh

PTSĆ0

87.890.276Ć01

Bus segment cable

Sprecher + Schuh

none

299.257.001

Bus segment 1m

Sprecher + Schuh

PCBĆ10

87.890.281Ć10

Connector

Sprecher + Schuh

none

87.890.283Ć01

Termination Block

Sprecher + Schuh

PCEĆ0

87.890.284Ć01

More Information...

Cabling and Equipment

Required for Line B Type
