Page 71

background image

2–51

How Communication Takes Place and I/O Image Table Mapping

Publication 1794ĆUM057B-EN-P - November 2001

Table 2.A

Configuring Your Outputs for the 1794ĆIF2XOF2I Analog Combo

Module

Configuration Bits

MSD

LSD

Nominal

Range

Data Type

Output Values

Hexadecimal

Decimal

Update

Rate

0

0

0

1

4Ć20mA

2' complement

<0000-7878>

<0000-30840>

5.0ms

0

0

1

0

+10V

2' complement

<8618-79E8>

<-31208-31208> 2.5ms

0

0

1

1

+5V

2' complement

<8618-79E8>

<-31208-31208> 2.5ms

0

1

0

0

0Ć20mA

2' complement %

0-10000>

0-10000>

5.0ms

0

1

0

1

4Ć20mA

2' complement %

<0-10000>

<0-10000>

5.0ms

0

1

1

0

0Ć10V

2' complement %

0-10000>

0-10000>

5.0ms

0

1

1

1

+10V

2' complement

<-10000-10000>

<-10000-10000> 5.0ms

1

0

0

0

0Ć20mA

binary

0000-F3CF>

0000-62415>

2.5ms

1

0

0

1

4Ć20mA

binary

0000-F0F1>

0000-61681>

5.0ms

1

0

1

0

0Ć-10V

binary

0000-F3CF>

0000-62415>

2.5ms

1

0

1

1

0Ć5V

binary

0000-F3CF>

0000-62415>

2.5ms

1

1

0

0

4Ć20mA

offset binary

<8000-F9E8>

32768-63976>

2.5ms

1

1

0

1

+20mA

offset binary

<8000-F878>

<32768-63608>

5.0ms

1

1

1

0

+10V

offset binary

<0618-F9E8>

<1560-63976>

2.5ms

1

1

1

1

+5V

offset binary

<0618-F9E8>

<1560-63976>

2.5ms

Word/Bit Descriptions for the 1794-IF2XOF2I Analog Combo
Module

Word

Decimal Bit

(Octal Bit)

Definition

Word 0

Bits 00-15

(00-17)

Input Channel 0 input data - 16Ćbit unipolar; 15Ćbit plus sign bipolar

Word 1

Bits 00-15

(00-17)

Input Channel 1 input data - 16Ćbit unipolar; 15Ćbit plus sign bipolar

Word 2

Bits 00-15

(00-17)

Read Back Output Channel 0 - During normal operation, it is a copy of the output of

channel 0. During an EN transition, it is the condition of the output as determined by

S1 and S0.

Word 3

Bits 00-15

(00-17)

Read Back Output Channel 1 - During normal operation, it is a copy of the output of

channel 1. During an EN transition, it is the condition of the output as determined by

S1 and S0.

Word 4

Bits 00-15

(00-17)

Real Time Sample. The fixed time period you set telling the module when to provide

data to the processor.
