Rockwell Automation 1794-APB/B FLEX I/O PROFIBUS Adapter Module User Manual User Manual
Page 15
1–3
Overview of FLEX I/O and Your PROFIBUS Adapter Module
Publication 1794ĆUM057B-EN-P - November 2001
!
ATTENTION
Do not use more than one cable per system.
Mounting Kit (1794ĆNM1)
Use the optional 1794-NM1 mounting kit to mount your system on a
panel or wall without a DIN rail.
20129
1794ĆNM1
Mounting Kit with
18 screws (2 screws for
the adapter and 2 screws
for each module)
