2–8 How Communication Takes Place and I/O Image Table Mapping
Publication 1794ĆUM057B-EN-P - November 2001
16Ćpoint Source Input Module Image Table Mapping - 1794ĆIV16
Module Image
Inputs
Delay
Time
Not used Not used
Input Size
Output Size
0 or 1 Word
1 or 2 Words
I/O Image
Not used
Read
Write
Memory Map of 16-Point Input Module Image Table –
1794-IV16
Dec. Bits 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 Size
Oct. Bits 17 16 15 14 13 12 11 10 07 06 05 04 03 02 01 00 Read/Write Words
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Read word 1
Not used FT for all channels Not used Writeword 1
Not used Writeword 2
Where D = Input Data
FT = Input filter Time
Input Filter Times for the 1794-IV16 Input Module
Bits Description
Selected
10 09 08 Filter Time for Inputs 00-15 (00-17)
Filter Time
0 0 0 Filter Time 0 (default) 216 µ s
0 0 1 Filter Time 1 512 µ s
0 1 0 Filter Time 2 1ms
0 1 1 Filter Time 3 2ms
1 0 0 Filter Time 4 4ms
1 0 1 Filter Time 5 8ms
1 1 0 Filter Time 6 16ms
1 1 1 Filter Time 7 32ms
