Index I–3
P
PLCĆ2 family processor, block transfer
programming, 3-2
PLCĆ3 family processor, block transfer
programming, 3-3
PLCĆ5 family processor, block transfer
programming, 3-4
PLCĆ5/250 processor, block transfer
programming, 3-5
power, requirements, 2-3
power requirements, 2-3
programming, PLC-3 example, C-8 , D-8
Programming example, PLC-3, C-8 ,
D-8
prover, 1-6
bidirectional, 1-6
gate input wiring, 2-10
range of operation, 4-7
unidirectional, 1-6
proximity probes, 1-2 , 1-4 , 2-9
S
shielded cable, 2-8ć2-9
specifications, CFM module, A-2
frequency accuracy, A-1
store count, 1-6
gate input wiring, 2-10
T
Totalizer and Nonresettable Totalizer modes
counting, 4-8
frequency sampling, 4-9
storing count values, 4-10
Totalizer mode, 1-4 , 1-5 , 1-6 , 1-7 ,
4-8
troubleshooting, 6-1
TTL, 1-2 , 1-4 , 2-9
W
warnings, guarding against ESD, 2-1
wiring arm connections
CFM (QRC) module, C-6
CFM (QRD) module, D-6 , D-7
CFM module, 2-8 , 2-9
