New/updated information, Abbreviations, Abbreviations new/updated information – Rockwell Automation 1771-CFM,D17716.5.99 CONFIGURABLE FLOWMET User Manual
Page 8
Using This Manual
P–2
Publication 1771Ć6.5.99 Ċ December 1995
The1771-CFM/B is marked with the
О
О
О
ОО
О
О
logo, indicating that this
version complies with the European Union Directives. Technical
additions and corrections are marked with change bars.
To comply with the European Union Directives, this information in
the manual has been updated:
Updated information On page(s)
European Union Directives compliance
2-2
CFM module field wiring arm connections
2-8
CFM module wiring examples
2-9
General specifications
A-1
CFM (QRC) module wiring arm connections
C-6
CFM (QRD) module wiring arm connections
D-6
,
D-7
We refer to As
Configurable Flowmeter module (1771ĆCFM/B)
CFM module
Configurable Flowmeter module emulating a 1771ĆQRC module
CFM (QRC) module
Configurable Flowmeter module emulating a 1771ĆQRD module
CFM (QRD) module
AllenĆBradley programmable logic controllers
PLC processors
1771ĆQRD Pulse Flowmeter module
QRD module
Bulletin 1771 Dual Ratemeter module (1771ĆQRC)
QRC module
