5–4 Interpret Module Status and Input Data
Publication 1771Ć6.5.99 - December 1995
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Percent of Full Scale (Rate % of High RPM value) Ċ
the calculated frequency scaled by the Highest
Allowable Frequency (BTW 8, 18, 28, 38) and then
expressed as a number from 0 to 32,767.
word 5 (Channel 0)
word 15 (Channel 1)
word 25 (Channel 2)
word 35 (Channel 3)
word 6 (Channel 0)
word 15 (Channel 1)
word 24 (Channel 2)
word 33 (Channel 3)
0 = 0%
32, 767 ≥ 100%
% = BTR word 6,15,24,33 / 32,767
For example, if:
BTW word 5 Ċ bit 12, 4 x Highest Hertz = 1 (ON)
bit 15, Frequency in 10ths = 0 (OFF)
BTW word 8 Ċ Highest Allowable Frequency = 21,750Hz
BTR word 7 = 1
BTR word 8 = 1410
word 8 (channel 0)
word 17 (channel 1)
word 26 (channel 2)
word 35 (channel 3)
word 7 (channel 0)
word 16 (channel 1)
word 25 (channel 2)
word 34 (channel 3)
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Frequency indicates the calculated frequency.
RANGE: 0Ć120,000
If Frequency in 10ths (word 5,15,25,35 Ċ bit 15) is:
not set Ċ MSD range = 0Ć12 x 10,000 / LSD range = 0Ć9,999
Example: If word 7 = 6 and word 8 = 532, Frequency = 6(10,000) + 532 = 60,532
set Ċ MSD range = 0Ć120 x 1,000 / LSD range = 0Ć9,999 x 0.10
Example: If word 7 = 6 and word 8 = 532, Frequency = 6(1,000) + 532(0.10) = 6,053.2
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
MSD Ć
range depends on
status of Frequency in 10ths
(BTW word 5,15,25,35 bit 15)
and mode of operation
LSD Ć range depends
on status of BTW
Frequency in 10ths bit
all
HR
Frequency = 11,410Hz
Percent Full Scale (BTR 6) = 32,767
(21,750 x 4) / 11,410
Percent Full Scale (BTR 6) = 4,297
T, NRT, HR
