Typical applications – Rockwell Automation 1771-CFM,D17716.5.99 CONFIGURABLE FLOWMET User Manual
Page 13
1–3
Overview of the CFM Module
Publication 1771Ć6.5.99 - December 1995
You can use the CFM module in the power management, automotive,
food and beverage, and oil and gas industries for various flow and/or
turbine metering applications. Some sample applications include:
•
turbine shaft speed monitoring
•
automotive paint booths
•
brewery flow monitoring
•
petrochemical flow and custody transfer
PLCĆ5/30
processor
1771ĆCFM
shaft speed
1771ĆOFE
pulse output
fuel
CV
turbine
generator
monitors fuel flow
and total gallons
PLC controller monitors shaft
speed, performs PID calculations
and adjusts valve.
power
supply
electricity
shaft
encoder
19885
Typical Applications
