Rockwell Automation Publication 1769-IN088A-EN-P - February 2011 89
I/O Memory Mapping Chapter 3
27 Reserved Input Data
Format Ch4 Reserved Input Type/Range
Select Ch4
28 SGN Process Alarm High Data Value Channel 4
29 SGN Process Alarm Low Data Value Channel 4
30 SGN Alarm Dead Band Value Channel 4
31 Reserved
32 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch5
33 Reserved Input Data
Format Ch5 Reserved Input Type/Range
Select Ch5
34 SGN Process Alarm High Data Value Channel 5
35 SGN Process Alarm Low Data Value Channel 5
36 SGN Alarm Dead Band Value Channel 5
37 Reserved
38 EC Reserved EA AL EI (1) Reserved Input Filter Sel Ch6
39 Reserved Input Data
Format Ch6 Reserved Input Type/Range
Select Ch6
40 SGN Process Alarm High Data Value Channel 6
41 SGN Process Alarm Low Data Value Channel 6
42 SGN Alarm Dead Band Value Channel 16
43 Reserved
44 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch7
45 Reserved Input Data
Format Ch7 Reserved Input Type/Range
Select Ch7
46 SGN Process Alarm High Data Value Channel 7
47 SGN Process Alarm Low Data Value Channel 7
48 SGN Alarm Dead Band Value Channel 7
49 Reserved
50 EC Reserved EA AL EI
(1)
Reserved Input Filter Sel Ch8
51 Reserved Input Data
Format Ch8 Reserved Input Type/Range
Select Ch8
52 SGN Process Alarm High Data Value Channel 8
53 SGN Process Alarm Low Data Value Channel 8
54 SGN Alarm Dead Band Value Channel 8
55 Reserved
56 EC Reserved EA AL EI (1) Reserved Input Filter Sel Ch9
57 Reserved Input Data
Format Ch9 Reserved Input Type/Range
Select Ch9
58 SGN Process Alarm High Data Value Channel 9
59 SGN Process Alarm Low Data Value Channel 9
60 SGN Alarm Dead Band Value Channel 9
61 Reserved
Wo
rd
Bit Position
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
