194 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Wo
rd
Bit Position
(1)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
13, 21,
29, 37 Output
Delay 0 0 ms 0 0 0 0 0 0 0 0 0 0
1 ms 0 0 0 0 0 0 0 0 0 1
Output
Delay 1 2 ms 0 0 0 0 0 0 0 0 1 0
3 ms 0 0 0 0 0 0 0 0 1 1
Output
Delay 2 4 ms 0 0 0 0 0 0 0 1 0 0
5 ms 0 0 0 0 0 0 0 1 0 1
Output
Delay 3 6 ms 0 0 0 0 0 0 0 1 1 0
7 ms 0 0 0 0 0 0 0 1 1 1
…
993 ms 1 1 1 1 1 0 0 0 0 1
994 ms 1 1 1 1 1 0 0 0 1 0
995 ms 1 1 1 1 1 0 0 0 1 1
996 ms 1 1 1 1 1 0 0 1 0 0
997 ms 1 1 1 1 1 0 0 1 0 1
998 ms 1 1 1 1 1 0 0 1 1 0
999 ms 1 1 1 1 1 0 0 1 1 1
1000 ms 1 1 1 1 1 0 1 0 0 0
(1) Shaded bit positions must be set to 0. Entering a binary value greater than 1111101000 (greater than 1000
decimal) results in a configuration error.
