86 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
1769-IF16V The following I/O memory mapping lets you configure the 1769-IF16V module.
Input Data File
For each module, slot
x, words 0…15 in the input data file contain the converted
value of the module’s analog input channels. Word 16 in the input data file
contains the time stamp value, if time stamping is enabled, that corresponds to
the module's last input data sampling period. Words 17…21 in the input data file
contain status bits for the analog input channels.
Define To Choose Make these bit settings
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
Input
Range
Select 4…20 mA 0 0 0 0
0…20 mA 0 0 0 1
Input
Data
Format
Select Proportional
Counts 0 0 0
Engineering
Units 0 0 1
Scaled for PID 0 1 0
Percent
Range 0 1 1
Wo
rd
Bit Position
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
0 SGN Analog Read (Input) Data Value Channel 0
1 SGN Analog Read (Input) Data Value Channel 1
2 SGN Analog Read (Input) Data Value Channel 2
3 SGN Analog Read (Input) Data Value Channel 3
4 SGN Analog Read (Input) Data Value Channel 4
5 SGN Analog Read (Input) Data Value Channel 5
6 SGN Analog Read (Input) Data Value Channel 6
7 SGN Analog Read (Input) Data Value Channel 7
8 SGN Analog Read (Input) Data Value Channel 8
9 SGN Analog Read (Input) Data Value Channel 9
10 SGN Analog Read (Input) Data Value Channel 10
11 SGN Analog Read (Input) Data Value Channel 11
12 SGN Analog Read (Input) Data Value Channel 12
13 SGN Analog Read (Input) Data Value Channel 13
14 SGN Analog Read (Input) Data Value Channel 14
15 SGN Analog Read (Input) Data Value Channel 15
16 Nu Time Stamp Value
