74 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
Define Indicate this These bit settings
15…1
1 10 9 8 7…
4 3 2 1 0
Input Range
Select -10 to +10V dc 0 0 0 0
0 to 5V dc 0 0 0 1
0 to 10V dc 0 0 1 0
4 to 20 mA 0 0 1 1
1 to 5V dc 0 1 0 0
0 to 20 mA 0 1 0 1
Input Data
Select Raw/Proportional
Counts 0 0 0
Engineering Units 0 0 1
Scaled for PID 0 1 0
Percent Range 0 1 1
