Output Data File

For each module, slot

x, words 0 and 1 in the output data file contain the control

program’s directed state of the module’s analog output channels. Word 2 contains
the cancel input channel alarm control bits. Word 3 contains the cancel output
channel clamp control bits.

The bits are defined as follows:

• SGN = Sign bit in 2’s complement format.
• CHIx = Cancel High Process Alarm Latch for Input x. Allows each input

high-process-alarm latch to be individually cancelled. Cancel = 1.

• CLIx = Cancel Low Process Alarm Latch for Input x. Allows each input

low-process-alarm latch to be individually cancelled. Cancel = 1.

• CHOx = Cancel High Clamp Alarm Latch for Output x. Allows each

output high-clamp-alarm latch to be individually cancelled. Cancel = 1.

• CLOx = Cancel Low Clamp Alarm Latch for Output x. Allows each

output low-clamp-alarm-latch to be individually cancelled. Cancel = 1.

Configuration Data File

The manipulation of bits from this file is normally done with programming
software, such as RSLogix 500, RSLogix 5000, or RSNetWorx for DeviceNet,
during initial configuration of the system. In that case, graphical screens provided
by the programming software simplify configuration.

Some systems, like the 1769-ADN DeviceNet adapter system, also allow the bits
to be altered as part of the control program using communication rungs. In that
case, it is necessary to understand the bit arrangement.

Wo

rd

Bit Position

15

14

13

12

11

10

09 08 07

06

05

04

03

02

01

00

0

SGN Analog Output Data Channel 0

0

0

1

SGN Analog Output Data Channel 1

0

0

2

0

0

0

0

0

0

0

0

CLI3 CHI3 CLI2 CHI2 CLI1

CHI1

CLI0

CHI0

3

0

0

0

0

0

0

0

0

0

0

0

0

CLO1 CHO1 CLO0 CHO0

Wo

rd

Bit Position

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

0

0

Real Time Sample Value

1

ETS

Reserved

2

EC

Reserved

EA

AL

EI

Reserved

Input Filter Sel ChI0

3

Reserved

Input Dta Fm
ChI0

Reserved

Inpt Tp/Rnge Sel
ChI0

4

SGN

Process Alarm High Data Value Channel 0

0
