160 Rockwell Automation Publication 1769-IN088A-EN-P - February 2011
Chapter 3 I/O Memory Mapping
+ Local:1:I.Ch4_5Status SINT Binary
Local:1:I.Ch4OverRange BOOL Decimal
Local:1:I.Ch4UnderRange BOOL Decimal
Local:1:I.Ch4InHold BOOL Decimal
Local:1:I.Ch5OverRange BOOL Decimal
Local:1:I.Ch5UnderRange BOOL Decimal
Local:1:I.Ch5InHold BOOL Decimal
+ Local:1:I.Ch6_7Status SINT Binary
Local:1:I.Ch6OverRange BOOL Decimal
Local:1:I.Ch6UnderRange BOOL Decimal
Local:1:I.Ch6InHold BOOL Decimal
Local:1:I.Ch7OverRange BOOL Decimal
Local:1:I.Ch7UnderRange BOOL Decimal
Local:1:I.Ch7InHold BOOL Decimal
+ Local:1:I.Ch0ReadBack INT Decimal
+ Local:1:I.Ch1ReadBack INT Decimal
+ Local:1:I.Ch2ReadBack INT Decimal
+ Local:1:I.Ch3ReadBack INT Decimal
+ Local:1:I.Ch4ReadBack INT Decimal
+ Local:1:I.Ch5ReadBack INT Decimal
+ Local:1:I.Ch6ReadBack INT Decimal
+ Local:1:I.Ch7ReadBack INT Decimal
Tag
Name Bit Indicates This
(1)
7 6 5 4 3 2 1 0
Combined
Status Ch7
Status Ch6
Status Ch5
Status Ch4
Status Ch3
Status Ch2
Status Ch1
Status Ch0
Status
Module
Status Power
Fail
Ch0_1
Status Ch1
InHold Ch1
Under
Range Ch1
Over
Range Ch0
InHold Ch0
Under
Range Ch0
Over
Range
Ch2_3
Status Ch3
InHold Ch3
Under
Range Ch3
Over
Range Ch2
InHold Ch2
Under
Range Ch2
Over
Range
Ch4_5
Status Ch5
InHold Ch5
Under
Range Ch5
Over
Range Ch4
InHold Ch4
Under
Range Ch4
Over
Range
Ch6_7
Status Ch7
InHold Ch7
Under
Range Ch7
Over
Range Ch6
InHold Ch6
Under
Range Ch6
Over
Range
(1) Bit positions left blank in table are always set to 0.
- Local:1:I AB:1769_OF8V:I:0
