ControlNet I/O MapĆEntry Status Words
Appendix D
and Error Messages
D-3
Possible Corrective Action(s) Explanation / Possible Cause(s) Error Message
Hex.
Code
Decimal
Code
273 0x0111
EXP NET PCKT TIME INVALID
The target node cannot produce the
data at or faster than the expected
net packet time entered in the map
table
Increase the expected net packet time
entered in the map table
511 0x01FF
INVALID WHEN NODE IS IDLE
The ControlNet cable to the target
node is broken and/or disconnected
Fix and/or reconnect the ControlNet cable to
the target node
The originating node attempted to open a
dataĆtransfer connection before a node
ti d
No power is being received by the
target node
Supply power to the target node
connection was opened
The target node is offline Correctly configure the target node as an
active node on the ControlNet network and
save your ControlNet configuration
The target adapter is in Processor
Restart Lockout
Press the reset button on the target adapter
513 0x0201
CONNECTION ALREADY CLOSED
The connection that the originating
node is trying to close has not been
opened by the target node
No action required
515 0x0203
CONNECTION TIMED OUT
The ControlNet cable to the target
node has become broken and/or
disconnected
Fix and/or reconnect the ControlNet cable to
the target node
Power is no longer being received
by the target node
Supply power to the target node
65281 0xFF01
CONNECTION REJECTED
The ControlNet cable to the target
node is broken and/or disconnected
Fix and/or reconnect the ControlNet cable to
the target node
No power is being received by the
target node
Supply power to the target node
The target node is offline Correctly configure the target node as an
active node on the ControlNet network and
save your ControlNet configuration
65294 0xFF0E
ATTRIBUTE CANNOT BE SET
Your program attempted to set an
attribute that cannot be set for
a specific moduleĊe.g., a CIO
Change your program so that it does not
attempt to set the attribute
a specific moduleĊe.g., a CIO
instruction tried to send safeĆstate
data to a flex module that does not
support safeĆstate data
Insert a module that can have this attribute
set
65299 0xFF13
NOT ENOUGH DATA
The transfer length is zero Increase the length of the transfer
The processor data table is too
small
Increase the size of the data table to
accommodate the transfer length
65301 0xFF15
TOO MUCH DATA
The transfer length is too large Decrease the length of the transfer
65522 0xFFF2
CONFIG FROM MAP ENTRY FAILED
The ControlNet cable to the target
node is broken and/or disconnected
Fix and/or reconnect the ControlNet cable to
the target node
No power is being received by the
target node
Supply power to the target node
The node or slot contains the wrong
module type
Insert the proper module in the correct slot of
the target node
An incorrect module type was
entered in the map table
Enter the correct module type in the mapĆ
table entry
65523 0xFFF3
CONTROLNET TRANSFER QUEUE FULL
The immediate CIO transfer could
not be executed because the queue
is full
Keep the number of active 1771 READ
and/or 1771 WRITE CIOs at or under the
maximum of 32
