Chapter 5

Monitoring and Troubleshooting Your

ControlNet System

5-17

Using the ControlNet WHO ACTIVEĊChannel Status Screen

Important: Keep the following in mind:

ControlNet WHO screens are available only when your programming

device is communicating through a 1784-KTC card, 1784-KTCx card,
or 1770-KFC interface on the ControlNet network.

When you view the WHO screens while your ControlNet system is

operating, you affect the performance of unscheduled I/O operations.

Follow the steps on the left to go to the ControlNet WHO ACTIVE—
Channel Status screen.

+–– ControlNet WHO ACTIVE – Channel Status ––––––––––––––––––––––––––––––––––––+

| Node Active Channel A Channel B Bad frame received from node number |

| Channel Status Status most recent to least recent |

|––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––|

| 01 A Good Inactive |

| 02 A Good Inactive |

| 03 A Good Inactive |

| 04 A Good Inactive |

| 05 |

| 06 |

| 07 |

| 08 |

| 09 |

| 10 |

| 11 |

| 12 |

+––– ESC exits ––[ WHO rate = 4 sec ]––––[ Maximum Unscheduled Nodes = 12 ]––––+

Press a function key, or page up or page down.

Net Channel A Status: Cable Good Net Channel B Status: Cable Inactive

Network Save Who

Diags Config Rate

F6 F9 F10

If you want to:

Press:

go to the ControlNet WHO ACTIVEĊNetwork Status screen

[F6]—Network

Diags

save the current ControlNet WHO configuration as the permanent ControlNet WHO configuration

[F9]—Save

Config

enter a new ControlNet WHO update rate

[F10]—WHO

Rate

go to the ControlNet WHO ACTIVEĊActive Node Identification screen

[Esc]

This field:

Displays:

Node

a device's network address

Active

Channel

the channel that the node is using

Channel

A

Status

the status of the channel A for the specified node

Good

= channel A is receiving no unusable frames

WARN

= channel A is receiving a low level of unusable frames

FAULTED

= channel A is receiving a high level of unusable frames; it is not usable

Inactive

= channel A is not currently active

WHO

Active
