Chapter 2 – Rockwell Automation 1785-L20C_L40C, D17856.5.14 ControlNet PLC-5 Programmable Controllers User Manual User Manual
Page 42

Chapter 2
Planning to Use Your ControlNet
PLCĆ5 Processor
2-14
Serial Connection
1770ĆKFC
Example of a ControlNet Network
PLCĆ5/40C
Personal Computer or
Personal Computer with 1784ĆKTCx or
1784ĆKTC Card and ControlView or
6200 Series Programming Software
Personal Computer with
1784ĆKTCx Card and ControlView or
6200 Series Programming Software
Other Serial Device and ControlView or
PLCĆ5/40C
Processor
in ControlNet NonĆcontrolling Mode
Interface
RemoteĆI/O Link
Data Highway Plus Link
1771ĆACN
Adapter
without Redundant Media
ControlNet Network
1794ĆACN Flex I/O Adapter
Controlling
Processor
6200 Series Programming Software
1770ĆKFC
PLCĆ5/40C
Processor
in ControlNet
Interface
RemoteĆI/O Link
Data Highway Plus Link
1771ĆACNR
Adapter
NonĆcontrolling Mode
Example of a ControlNet Network
with Redundant Media
ControlNet Network
Serial Connection
PLCĆ5/40C
Personal Computer or
Personal Computer with 1784ĆKTCx or
1784ĆKTC Card and ControlView or
6200 Series Programming Software
Personal Computer with
1784ĆKTCx Card and ControlView or
6200 Series Programming Software
Other Serial Device and ControlView or
Controlling
Processor
6200 Series Programming Software
See page 3-4 for more information on ControlNet node configuration.
