Chapter 3
Configuring Your ControlNet System
3-2
Follow the steps on the left to go to the ControlNet Node Information
(Monitor) screen. If the ControlNet information in the processor does not
match that on the current ControlNet link, the software redisplays the
Channel Overview screen with a new prompt and set of function keys.
Channel Overview
Channel 0: SYSTEM (POINT-TO-POINT)
Channel 1A: DH+
Channel 1B: SCANNER MODE
Channel 2: CONTROLNET
Channel 3A: UNUSED
PROCESSOR CONFIGURATION IS INCONSISTENT WITH CURRENT CONTROLNET CONFIGURATION.
Press F10 apply processor to CNet.
>
Rem Prog Forces:None 5/40C File CN
Apply
to Link
F10
If you want to: Do this:
apply the processor configuration information to the current
ControlNet link configuration, then go to the ControlNet Node
Information (Monitor) screen
Press
[F10]—Apply to Link
return to the original Channel Overview screen Press
[Esc]
Channel
Overview
6200
Main Menu
General
Utility
F3
Online
Program
Offline
Program
F1
F7
or
F4
Channel
Configuration
F5
(Monitor)
Move cursor to
Channel 2: CONTROLNET
Matching the Processor
Configuration with the
ControlNet Configuration
