Chapter 1

Installing Your ControlNet PLCĆ5 Processor

1-2

Before installing your ControlNet PLC-5 processor:

1.

Complete the following:

determine the proper environment
configure the proper grounding
route the conductors properly

For detailed information on completing these tasks, see the
Enhanced and Ethernet PLC-5 Programmable Controllers
User Manual, publication 1785-6.5.12.

2.

Check your processor package, and make sure that you have
the following:

Processor

ControlNet PLCĆ5

R

Programmable Controller,

1785ĆL20C or ĆL40C

1

Lithium Battery, 1770ĆXYC

1

DIN connector cover

Contents of Tray

1

DIN connector cover

4

Terminating resistorsĊ150W

2 or 4

Terminating resistorsĊ82W

y

g

2 or 4

3Ćpin connectors

2

Keys

y

1

Battery cover with screw

1

1784ĆCP7 cable adapter for 1784ĆCP, ĆCP5 cables

ControlNet PLCĆ5 Programmable Controllers User Manual,

publication 1785Ć6.5.14

Documentation

publication 1785Ć6.5.14

ControlNet PLCĆ5 Programmable Controllers Release Notes,

publication 1785Ć6 5 14ĆRN1

publication 1785Ć6.5.14ĆRN1

CSA Hazardous Location Approval Supplemental Information,

publication AGĆ4 1

publication AGĆ4.1

Enhanced and Ethernet PLCĆ5 Programmable Controllers User

Manual publication 1785 6 5 12

Manual, publication 1785Ć6.5.12

Guidelines for Handling Lithium Batteries, publication AGĆ5.4
Industrial Automation Wiring and Grounding Guidelines,

publication 1770Ć4.1

Identified by four colored bands: brown, green, brown, and gold

Two with a PLCĆ5/20C processor, four with a PLCĆ5/40C processor

Identified by four colored bands: gray, red, black, and gold

If any items are missing or incorrect, contact your local
Allen-Bradley Company, Inc. sales office or distributor.
