Chapter 1
Installing Your ControlNet PLCĆ5 Processor
1-20
The following ControlNet cable system components are available from the
Allen-Bradley Company, Inc.:
Item ① Cat. No.
ControlNet Coax Tool Kit 1786ĆCTK
RightĆangle TĆtap 1786ĆTPR
Coax Tap Kit
Straight TĆtap 1786ĆTPS
Coax Tap Kit
RightĆangle YĆtap 1786ĆTPYR
Straight YĆtap 1786ĆTPYS
Repeaters
HighĆvoltage ac & dc 1786ĆRPT
Repeaters
LowĆvoltage dc 1786ĆRPTD
RGĆ6 Quad Shield Cable StandardĆPVC CMĆCL2 1786ĆRG6
ControlNet Network Access CableĊ3.05 m (10 ft) 1786ĆCP
Barrel (plug to plug) 1786ĆBNCP
BNC/RGĆ6 plug 1786ĆBNC
BNC Connectors Bullet (jack to jack) 1786ĆBNCJ
IsolatedĆbulkhead (jack to jack) 1786ĆBNCJI
Terminators (BNCĆ75
Ω ) 1786ĆXT
① For a complete list of ControlNet cable system components that are
available from AllenĆBradley Company, Inc. and other sources, see
the ControlNet Cable System Component List, publication AGĆ2.2.
Important: Install all wiring for your ControlNet system in accordance
with the regulations contained in the National Electric Code (or applicable
country codes), state codes, and applicable municipal codes.
For detailed information on ControlNet cabling, see the following:
Publication Publication Number
ControlNet Cable System Component List AGĆ2.2
ControlNet Cable System Planning and Installation Manual 1786Ć6.2.1
ControlNet Coax Tap Installation Instructions 1786Ć2.3
ControlNet Network Access Cable Installation Instructions 1786Ć2.6
ControlNet Repeater Installation Instructions 1786Ć2.7
Industrial Automation Wiring and Grounding Guidelines 1770Ć4.1
