Chapter 5

Monitoring and Troubleshooting Your

ControlNet System

5-10

Do this:

If you want to:

clear the inhibit bit so that the processor

will attempt to establish a connection with

the module or message

1. Move the cursor to the

Inhibit

field for that entry

2. Type a

0

3. Press

[Enter]

set the reset bit so that the processor will

set the output module or message's

Run/Program command to Program

mode

1. Move the cursor to the

Reset

field for that entry

2. Type a

1

3. Press

[Enter]

clear the reset bit so that the processor

will set the output module or message's

Run/Program command to the

processor's mode

1. Move the cursor to the

Reset

field for that entry

2. Type a

0

3. Press

[Enter]

return to the ControlNet I/O Mapping

(Monitor) screen

Press

[Esc]
