5–29 Programming
[Flt Motor Mode]
This parameter displays the motor mode active at
the time of the last fault.
Parameter Number 143
Parameter Type Read Only
Factory Default None
Units Display Drive
“1” 1 Power up sequence in progress
“2” 2 Motor connected, drive off
“3” 3 DC boost being applied
“4” 4 Motor running at [Dwell Frequency]
“5” 5 Motor accelerating
“6” 6 Motor at command speed
“7” 7 Motor decelerating
“8” 8 Motor coasting
“9” 9 Motor under DC braking
“10” 10 Waiting for fault reset – returns to 0
“11” 11 Start mode
“12” 12 Flying start search enable
“13” 13 Flying start w/encoder in process
[Flt Power Mode]
This parameter displays the power mode active at
the time of the last fault. These values can be
helpful in troubleshooting for a condition causing a
fault.
Parameter Number 144
Parameter Type Read Only
Factory Default None
Units Display Drive
“1” 1 Power up sequence in progress
“2” 2 Precharge in progress
“3” 3 Bus voltage being stored in memory
“4” 4 Ready for run cmnd. after power up
“5” 5 Power stage diagnostics running
“6” 6 Line loss detection occurred
“7” 7 Ready for run command after stop
“8” 8 Drive running
“9” 9 Motor flux decay delay
“10” 10 DC braking in progress
“11” 11 Drive fault occurred
“12” 12 Flying start search enabled
“13” 13 Deceleration in progress
“14” 14 SCR wake mode
“15” 15 SCR check mode
“16” 16 SCR wait mode
[Fault Frequency]
This parameter stores and displays the last
[Output Freq] prior to a fault.
Parameter Number 145
Parameter Type Read Only
Display Units / Drive Units 0.01 Hertz / 32767 = Maximum Freq.
Factory Default None
Minimum Value 0.00 Hz
Maximum Value 400.00 Hz
Faults
