Chapter
5
Programming
Chapter 5 describes parameter information for the 1336 PLUS. Pa-
rameters are divided into 14 groups for ease of programming and
operator access. Grouping replaces a sequentially numbered parame-
ter list with functional parameter groups that increases operator
efficiency and helps to reduce programming time. For most applica-
tions, this means simplicity at startup with minimum drive tuning.
The Function Index shown below provides a directory of the
parameters required for each drive function. The Page Number
locates within a group all parameters associated with that specific
function.
Function Page Number
Analog Invert 5–14
Auto Restart 5–20
Custom Volts-per-Hertz 5–13
DC Brake-to-Stop 5–16
DC Hold Brake 5–16
Dwell 5–20
Encoder Feedback 5–43
Fault Buffer History 5–27
Frequency Select 5–18
Output Configuration 5–25
Minimum/Maximum Frequency 5–9
Overload Protection 5–10
Preset Frequencies 5–18
Process Display 5–42
Remote I/O 5–41
Ride Thru 5–11
S-Curve Acceleration 5–21
Skip Frequencies 5–19
Slip Compensation 5–20
Sync Function 5–24
Traverse Function 5–23
The flow chart provided on pages 5–2 and 5–3 highlight the steps
required to access each group of parameters and lists all parameters
for each group.
Important: Series A (Version 3.0) and Series B HIM software ver-
sions (see back of HIM) provide several new functions,
including; Search, Control Status and Bit ENUMs. Re-
fer to Chapter 3 for a description of these functions.
Function Index
Programming Flow Chart
