1–2 Information and Precautions
!
ATTENTION: An incorrectly applied or installed
drive can result in component damage or a reduction in
product life. Wiring or application errors, such as,
undersizing the motor, incorrect or inadequate AC
supply, or excessive ambient temperatures may result
in malfunction of the system.
!
ATTENTION: Only personnel familiar with the
1336 PLUS Adjustable Frequency AC Drive and
associated machinery should plan or implement the
installation, start-up and subsequent maintenance of the
system. Failure to comply may result in personal
injury and/or equipment damage.
!
ATTENTION: To avoid a hazard of electric shock,
verify that the voltage on the bus capacitors has
discharged before performing any work on the drive.
Measure the DC bus voltage at the + & – terminals of
TB1. The voltage must be zero.
The diagram on the following page describes the 1336 PLUS catalog
numbering scheme.
1336S
First Position
Bulletin Number
BR
Second Position
Voltage
Letter Voltages
AQ 200-240V AC or
310V DC
BR 380-480VAC or
513-620V DC
A 200-240V AC
B 380-480V AC
F50
Third Position
Nominal HP Rating
Code kW (HP)
F20 1.5 (2)
F50 3.7 (5)
F50 3.7 (5)
F100 7.5 (10)
015 11 (15
010 7.5 (10)
030 22 (30)
AA
Fourth Position
Enclosure Type
Code Type
AA NEMA 1 (IP 20)
AE NEMA 1 (IP 20)/
EMC
AF NEMA 4 (IP 65)
AJ NEMA 12 (IP 54)
AN Open (IP 00)
EN30
Fifth Position
Language
Code Language
EN30 English/English V2.04
MODS
Sixth Position
Options
Code Description
Human Interface Module, IP 20 (Type 1)
HAB Blank – No Functionality
HAP Programmer Only
HA1 Programmer/Controller w/Analog Pot
HA2 Programmer/Controller w/Digital Pot
Human Interface Module, IP 65/54 (Type 4/12)
HJP Programmer Only
HJ2
Programmer/Controller w/Digital Pot
Code Description
Communication Options
GM1 Single Point Remote I/O
GM2 RS–232/422/485, DF1 & DH485
GM5 DeviceNet
Control Interface Options
L4 TTL Contact
L4E TTL Contact & Encoder Feedback
L5 24V AC/DC
L5E 24V AC/DC & Encoder Feedback
L6 115V AC
L6E 115V AC & Encoder Feedback
Catalog Number Explanation
