5–25 Programming
This group of parameters contains the programming options for digital and analog drive
outputs.
Output Config
[Digital Out Sel]
This parameter sets the condition that closes the
output contact at TB2 terminals 10 & 11.
Parameter Number 158
Parameter Type Read and Write
Factory Default “At Speed”
Units Display Drive
“At Speed” 0
“At Frequency” 1 Requires value in [Dig Out Freq]
“At Current” 2 Requires value in [Dig Out Curr]
“At Torque” 3 Requires value in [Dig Out Torque]
[Dig Out Freq]
This value sets the trip point for the output contact at
TB2 terminals 10 & 11 when [Digital Out Sel] is set
to “At Frequency”. The contact will be closed when
above this value.
Parameter Number 159
Parameter Type Read and Write
Display Units / Drive Units 0.01 Hertz / 32767 = Max Freq
Factory Default 0.00 Hz
Minimum Value 0.00 Hz
Maximum Value Programmed [Maximum Freq]
[Dig Out Current]
This value sets the trip point for the output contact at
TB2 terminals 10 & 11 when [Digital Out Sel] is set
to “At Current”. The contact will be closed when
above this value.
Parameter Number 160
Parameter Type Read and Write
Display Units / Drive Units 0% / 4096 = 100% of Drive Rated Amps
Factory Default 0 %
Minimum Value 0 %
Maximum Value 200 %
[Dig Out Torque]
This value sets the trip point for the output contact at
TB2 terminals 10 & 11 when [Digital Out Sel] is set
to “At Torque”. The contact will be closed when
above this value.
Parameter Number 161
Parameter Type Read and Write
Display Units / Drive Units 0.1 Amps / 4096 = Rated Torque Amps
Factory Default 0.0 Amps
Minimum Value 0.0 Amps
Maximum Value 200% of [Rated Amps]
[Analog Out Sel]
This parameter selects the source that will drive the
analog output.
Parameter Number 25
Parameter Type Read and Write
Factory Default “Frequency”
Units Display Drive
“Frequency” 0 Zero to programmed [Maximum Freq]
“Current” 1 Zero to 200%
“Torque” 2 Zero to 200%
“Power” 3 Zero to 200% kW
“Encoder” 4 Zero to [Pulse/Enc Hertz]
“Speed Adder” 5 Zero to [Speed Adder}
[Anlg Out Offset]
This parameter enables the voltage or current offset
for the analog output TB2 terminals 4 & 9. This
internal value offsets 0-20mA to 4-20mA and
0-10V to 2-10V.
Parameter Number 154
Parameter Type Read and Write
Factory Default “Disabled”
Units Display Drive
“Disabled” 0
“Enabled” 1
