C–2

CE Conformity

Filter Selection

Filter Catalog
Number

Three-Phase
Volts

Used with . . .

Frame
Reference

1336-RFB-16-A

200-240V

1336S-AQF15 - AQF20

1336 RFB 16 A

380-480V

1336S-BRF30 - BRF50

A2-A3

1336-RFB-30-A

200-240V

1336S-AQF30 - AQF50

1336 RFB 30 A

380-480V

1336S-BRF75, BRF100

1336-RFB-27-B

200-240V

1336S-A007

1336 RFB 27 B

380-480V

1336S-B007 - B015

1336-RFB-48-B

200-240V

1336S-A010 - A015

1336 RFB 48 B

380-480V

1336S-B020 - B030

EMC Enclosure Kit Selection

Frame

Enclosure Kit Catalog Number

Frame
Reference

200-240V Rating

380-480V Rating

500-600V Rating

A2, A3

1336S-AE3

–

1336S-AE2

1336S-AE4

RFI Filter Installation

Important:

Refer to the instructions supplied with the filter for details.

The RFI filter must be connected between the incoming AC supply
line and the drive input terminals.

RFI Filter Leakage Current

The RFI filter may cause ground leakage currents. Therefore a solid
ground connection must be provided as shown below.

ATTENTION: To guard against possible equipment
damage, RFI filters can only be used with AC supplies
that are nominally balanced and grounded with respect
to ground. In some installations, three-phase supplies
are occasionally connected in a 3-wire configuration
with one phase grounded (Grounded Delta). The filter
must not be used in Grounded Delta supplies.

Filter
