‎Chapter 5 Configuring T H E P M 1 3 0 P L U S
Configuring C O M M U N I C A T I O N S
PM130 PLUS Powermeter Series 67
NOTES
1. The meter provides the permanent
Modbus TCP server on port 502.
2. Selecting the DNP3 TCP service port launches the second DNP3
TCP server allowing simultaneous connections on both TCP
ports. Selecting the Modbus TCP port disables the DNP3 TCP
server.
The TCP service port can also be changed trough the COM2
serial port setup. Changing the communication protocol for the
port automatically changes the TCP port for the Ethernet.
3. When you change the device network settings through the
Ethernet port, the device port restarts so communication will
be temporarily lost. You may need to wait some additional time
until PAS restores a connection with your device.
Setting Up GPRS Network
The PM130 PLUS can provide wireless GPRS communications with the
remote Modbus/TCP server via GPRS modem module. See
Connecting a
GSM/GPRS modem in Chapter 2 on how to connect a modem to your
meter.
To set up GPRS communications:
1. Select Communications Setup from
the Meter Setup menu, and then click
on the GPRS Setup tab.
Figure ‎5-3: Communication Setup Dialog Box – GPRS Setup Tab
The following table lists available GPRS options.
