Chapter 4 Using
P A S S O F T W A R E
Authorization
PM130 PLUS Powermeter Series
63
3. Click on the tab of the setup you want to read from the meter.
As the dialog box opens, PAS retrieves and displays the
present setup data from the meter. Click Receive if you wish
to retrieve the meter setup once again.
4. To store the setup to the meter site database, click Save As,
and then click OK.
Batch Upload
To upload all setups from the device to the site database at once:
1. Check the On-line button on the
toolbar.
2. Select the device site from the list box on the toolbar.
3. Select Upload Setups from the Meter Setup menu.
4.5 Authorization
If communications with your meter is secured, you are prompted for the
password when you send new setup data to the meter.
Figure 4-5: Authorization Dialog Box
Enter the password and click OK.
If your authorization was successful, you are not prompted for the
password again until you close the dialog box.
in Chapter 5 for more information on the
meter password security.
