Chapter 3 Using
F R O N T D I S P L A Y
Data
D I S P L A Y
46
PM130 PLUS Powermeter Series
This function is not operational if the meter is password protected and the
simple reset is not allowed in protected mode (see
.
Common Measurements Display
Scroll through pages with the UP and DOWN arrow buttons.
Table 3: Common Measurements (Regular version)
1
L
V12
V23
V31
Line-to-line volts
2
P
V1
V2
V3
Line-to-neutral volts (in 4LN3,
3LN3, 3BLN3 configurations)
3
I1
I2
I3
Amps
4
kVA/MVA
PF
kW/MW
Total VA
Total PF
Total W
5
In
Hz
kvar/Mvar
Neutral current
Frequency
Total var
6
Ph.L1
PF
kW/MW
Phase L1 powers
(if enabled)
7
kVA/MVA
Ph.L1
kvar/Mvar
Phase L1 powers
(if enabled)
8
Ph.L2
PF
kW/MW
Phase L2 powers
(if enabled)
9
kVA/MVA
Ph.L2
kvar/Mvar
Phase L2 powers
(if enabled)
10
Ph.L3
PF
kW/MW
Phase L3 powers
(if enabled)
11
kVA/MVA
Ph.L3
kvar/Mvar
Phase L3 powers
(if enabled)
12
H01
PF
kW/MW
Fundamental total powers
(PM130EH, if enabled)
13
H1.L1
PF
kW/MW
Fundamental phase L1 powers
(PM130EH, if enabled)
14
H1.L2
PF
kW/MW
Fundamental phase L2 powers
(PM130EH, if enabled)
15
H1.L3
PF
kW/MW
Fundamental phase L3 powers
(PM130EH, if enabled)
16
U.Unb
V% unb
Voltage unbalance, percent
17
C.Unb
I% unb
Current unbalance, percent
