‎Chapter 5 Configuring T H E P M 1 3 0 P L U S
Configuring C O M M U N I C A T I O N S
66 PM130 PLUS Powermeter Series
Using PAS
Select Communications Setup from the Meter Setup menu, and then
click on the Network Setup tab.
Figure ‎5-2: Communication Setup Dialog Box – Network Setup Tab
The table below lists available network options.
Table 15: Ethernet Setup Options
Display Label Parameter Options Default
A Device IP Address 192.168.0.203
- Network Subnet Mask 255.255.255.0
G Network Default Gateway 192.168.0.1
- TCP Service Port 502 = Modbus/TCP
20000 = DNP3/TCP
502
