‎Chapter 3 Using F R O N T D I S P L A Y Data D I S P L A Y
PM130 PLUS Powermeter Series 47
Table 4: Common Measurements (Amp-Demand version)
1 I1
I2
I3
Amps
2 In Neutral current
Min/Max and Maximum Demand Display
1. Press the MAX/MIN button.
The MIN, MAX, or MAX DMD LED is illuminated when in the
MIN/MAX display.
2. Use the UP and DOWN arrow buttons to scroll through the
Min/Max and Max. Demand pages.
To see the time and date of the event occurrence:
1. Press simultaneously the SELECT and
UP buttons.
2. Use the UP and DOWN arrow buttons to scroll through the
parameters displayed on the page. A corresponding LED at the
right is illuminated showing the parameter for which the
timestamp is displayed.
The time is displayed in format hh.mm, and the date in format MM-DD-YY
(default) or in any other format you can select via the display setup (see
Configuring the Display ).
Note that Volts readings are line-to-neutral in 4LN3, 3LN3 and 3BLN3
wiring modes, and line-to-line in other modes.
Table 5: Min/Max and Maximum Demands (Regular version)
1 MIN V1/V12
V2/V23
V3/V31
Minimum volts
2 MIN I1
I2
I3
Minimum amps
3 MIN kVA/MVA
PF
kW/MW
Minimum total VA
Minimum total PF (absolute)
Minimum total W
4 MIN In
Hz
kvar/Mvar
Minimum neutral current
Minimum frequency
Minimum total var
5 MAX V1/V12
V2/V23
V3/V31
Minimum volts
6 MAX I1
I2
I3
Maximum amps
7 MAX kVA/MVA
PF
kW/MW
Maximum total VA
Maximum total PF (absolute)
Maximum total W
8 MAX In
Hz
kvar/Mvar
Maximum neutral current
Maximum frequency
Maximum total var
9 MAX V1/V12 Maximum volt demands
