‎Appendix C S E T P O I N T T R I G G E R S A N D A C T I O N S
PM130 PLUS Powermeter Series 143
Appendix C Setpoint Triggers and
Actions
Table 35: Setpoint Triggers
Display Code Designation Description
nonE NONE None (condition is not active)
Status Inputs
S1.On STAT INP #1 ON Status input #1 ON
S2.On STAT INP #2 ON Status input #2 ON
S3.On STAT INP #3 ON Status input #3 ON
S4.On STAT INP #4 ON Status input #4 ON
S1.OFF STAT INP #1 OFF Status input #1 OFF
S2.OFF STAT INP #2 OFF Status input #2 OFF
S3.OFF STAT INP #3 OFF Status input #3 OFF
S4.OFF STAT INP #4 OFF Status input #4 OFF
Relays
r1.On RELAY #1 ON Relay #1 ON
r2.On RELAY #2 ON Relay #2 ON
r1.OFF RELAY #1 OFF Relay #1 OFF
r2.OFF RELAY #2 OFF Relay #2 OFF
Phase Reversal
POS.P.r POS PHASE REVERSAL Positive phase rotation reversal
nEG.P.r NEG PHASE REVERSAL Negative phase rotation reversal
Low/High 1-Cycle Values on any Phase
r.Hi. U HI VOLT RT 1 High voltage
r.Lo. U LO VOLT RT 1 Low voltage
r.Hi. C HI AMPS RT High current
r.Lo. C LO AMPS RT Low current
r.thd.U HI V THD 2 High voltage THD
r.thd.C HI I THD 2 High current THD
r.HFc.C HI KF RT High K-Factor
r.tdd.C HI I TDD High current TDD
1-Cycle Auxiliary Values
r.Hi.Fr HI FREQ RT High frequency
r.Lo.Fr LO FREQ RT Low frequency
r.U.Unb HI V UNB% RT 1 High voltage unbalance
r.C.Unb HI I UNB% RT High current unbalance
1-Sec Phase Values
A.Hi.C1 HI I1 AVR High I1 current
A.Hi.C2 HI I2 AVR High I2 current
A.Hi.C3 HI I3 AVR High I3 current
A.Lo.C1 LO I1 AVR Low I1 current
A.Lo.C2 LO I2 AVR Low I2 current
A.Lo.C3 LO I3 AVR Low I3 current
1-Sec Values on any Phase
A.Hi. U HI VOLT AVR 1 High voltage
A.Lo. U LO VOLT AVR 1 Low voltage
A.Hi. C HI AMPS AVR High current
A.Lo. C LO AMPS AVR Low current
