Page 30: Relay outputs
Chapter 2 Installation
I
/ O C O N N E C T I O N S
30
PM130 PLUS Powermeter Series
2.5 I/O Connections
Before I/O Module installation ensure that all incoming
power sources are shut OFF. Failure to observe this practice
can result in serious or even fatal injury and damage to
equipment.
Figure 2-17 Module Connector Cover – Before Module Assembly
4DI/2DO Module
Figure 2-18 4DI/2DO Module Assembly
Relay Outputs
There are two relay outputs provided for energy pulsing, alarms, or
remote control.
