Appendix D Parameters for
D A T A M O N I T O R I N G A N D L O G G I N G
150
PM130 PLUS Powermeter Series
Designation
Description
kVAh L1
kVAh total L1
kVAh L2
kVAh total L2
kVAh L3
kVAh total L3
%HD V1
V1/V12 Harmonic Distortions
EH
1
V1 %HD01
H01 Harmonic distortion
V1 %HD02
H02 Harmonic distortion
…
...
V1 %HD40
H40 Harmonic distortion
%HD V2
V2/V23 Harmonic Distortions
EH
1
V2 %HD01
H01 Harmonic distortion
V2 %HD02
H02 Harmonic distortion
…
...
V2 %HD40
H40 Harmonic distortion
%HD V3
V3/V31 Harmonic Distortions
EH
1
V3 %HD01
H01 Harmonic distortion
V3 %HD02
H02 Harmonic distortion
…
...
V3 %HD40
H40 Harmonic distortion
%HD I1
I1 Harmonic Distortions
EH
I1 %HD01
H01 Harmonic distortion
I1 %HD02
H02 Harmonic distortion
…
...
I1 %HD40
H40 Harmonic distortion
%HD I2
I2 Harmonic Distortions
EH
I2 %HD01
H01 Harmonic distortion
I2 %HD02
H02 Harmonic distortion
…
...
I2 %HD40
H40 Harmonic distortion
%HD I3
I3 Harmonic Distortions
EH
I3 %HD01
H01 Harmonic distortion
I3 %HD02
H02 Harmonic distortion
…
...
I3 %HD40
H40 Harmonic distortion
ANG V1
V1/V12 Harmonic Angles
EH
1
V1 H01 ANG
H01 Harmonic angle
V1 H02 ANG
H02 Harmonic angle
…
...
V1 H40 ANG
H40 Harmonic angle
ANG V2
V2/V23 Harmonic Angles
EH
1
V2 H01 ANG
H01 Harmonic angle
V2 H02 ANG
H02 Harmonic angle
…
...
V2 H40 ANG
H40 Harmonic angle
ANG V3
V3/V31 Harmonic Angles
EH
1
V3 H01 ANG
H01 Harmonic angle
V3 H02 ANG
H02 Harmonic angle
…
...
V3 H40 ANG
H40 Harmonic angle
ANG I1
I1 Harmonic Angles
EH
I1 H01 ANG
H01 Harmonic angle
