‎Chapter 3 Using F R O N T D I S P L A Y Using T H E M E N U S
PM130 PLUS Powermeter Series 55
 the bottom item acts as an assisting exit window.
To select a menu entry from the main menu:
1. If the upper item is not highlighted, use
the SELECT button to activate it.
Figure ‎3-4: Main Menu
2. Scroll through the menu list by pressing briefly the UP or
DOWN arrow buttons until the required menu entry appears.
3. Press the ENTER button.
Viewing and Changing Setup Options
A second level menu normally consists of three items:
 the upper static window indicates the menu name
 the middle window represents a list of setup parameters you can
scroll through
 the lower window shows the parameter value.
To select a parameter you want to view or change:
1. Highlight the middle window by
pressing the SELECT button.
Figure ‎3-5: Selecting a Parameter
2. Scroll through the parameter list with the UP or DOWN arrow
buttons until the required parameter name appears.
To change the selected parameter:
1. Press the SELECT button to highlight
the lower item.
Figure ‎3-6: Changing a Parameter
2. If the parameter is represented by a list of values, select the
required option with the UP or DOWN arrow buttons.
3. If the parameter is represented by a numeric value, adjust the
number with the UP or DOWN arrow buttons. When the
button is briefly pressed and released, the number is
incremented or decremented by one. When the button is
