Chapter 3 Using
F R O N T D I S P L A Y
Data
D I S P L A Y
PM130 PLUS Powermeter Series
49
19
39.
V1/V12 HD%
V2/V23 HD%
V3/V31 HD%
Order 39 harmonic distortion
Table 9: Individual Current Harmonics
1
3.
I1 HD%
I2 HD%
I3 HD%
Order 3 harmonic distortion
2
5.
I1 HD%
I2 HD%
I3 HD%
Order 5 harmonic distortion
…
19
39.
I1 HD%
I2 HD%
I3 HD%
Order 39 harmonic distortion
Energy Display (PM130E/EH)
1. Press the ENERGY button.
The kVAh, kvarh, or kWh LED is illuminated.
2. If TOU registers are configured in the meter, you can press the
button again to scroll through all active TOU registers.
3. Use the UP and DOWN arrow buttons to scroll through energy
pages.
Per phase energy accumulators are displayed along with total energies if
phase energy calculation is enabled in the Device Options setup.
Table 10: Total and Phase Energies
1
Ac.i
1234
56789
Total kWh import
2
rE.i
1234
56789
Total kvarh import
3
AP.
1234
56789
Total kVAh
4
Ac.E
1234
56789
Total kWh export
5
rE.E
1234
56789
Total kvarh export
6
Ac.i 1
1234
56789
Phase L1 kWh import
7
rE.i 1
1234
56789
Phase L1 kvarh import
8
AP. 1
1234
56789
Phase L1 kVAh
