‎Chapter 6 Device C O N T R O L A N D U P G R A D I N G
Updating T H E M E T E R C L O C K
108 PM130 PLUS Powermeter Series
To change the time or date:
1. Use the UP and DOWN arrow buttons
to select a setup option
2. Highlight an item you want to change
by pressing briefly the SELECT button.
3. When you access the time setup display, the hours and
minutes are frozen allowing you to adjust the time.
4. Adjust the selected item with the UP and DOWN arrow
buttons.
5. Highlight the next item to change and adjust it in the same
manner.
6. Press ENTER to confirm your changes or press ESC to leave
the clock settings unchanged.
7. If you confirm the time change while the seconds are
highlighted, the seconds are zeroed; otherwise they stay
unchanged.
8. Press ESC to exit the menu.
Table 32 describes available options.
Table 32: Clock Setup Options
Display
Label
Parameter Options Description
hour Time hh.mm.ss The time is displayed as hh.mm.ss, where
the hours and minutes are shown in the
middle window separated by a dot, and
the seconds - in the lower window.
dAte Date YY.MM.DD
MM.DD.YY
DD.MM.YY
The date is displayed as per the user
definition, where the first two items are
shown in the middle window, and the last
one - in the lower window. See
Configuring the Display for instructions on
how to select the date format.
dAY Day of week Sun = Sunday
 on = Monday
tuE = Tuesday
WEd = Wednesday
thu = Thursday
Fri = Friday
Sat = Saturday
The day of the week is set automatically
when you change the date.
Using PAS
Ensure that the On-line button on the PAS toolbar is checked, and then
select RTC from the Monitor menu or click on the Real-Time Clock
button on the PAS toolbar.
The RTC dialog box displays the current PC time and the time in your
meter.
