Parameter data transfer
DRIVECOM parameter data channel
Reading parameters
8
l
93 EDSMF2133IB EN 5.0
Result:
ƒ Request telegram from master to drive:
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
01
hex
00
hex
5F
hex
C2
hex
00
hex
00
hex
00
hex
00
hex
00000001
bin
00000000
bin
01011111
bin
11000010
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
Waiting for change of handshake bit in the response (bit 6 here: 0 à 1)
ƒ Response telegram from drive to master (for error−free execution):
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Service Subindex Index
(High byte)
Index
(Low byte)
Data 4 Data 3 Data 2 Data 1
30
hex
00
hex
5F
hex
C2
hex
00
hex
06
hex
8F
hex
B0
hex
00110000 bin 00000000 bin 01011111 bin 11000010 bin 00000000 bin 00000110 bin 10001111 bin 10110000 bin
