Process data transfer
Lenze device control
Process data signals for 8200 vector frequency inverters
7
l
52 EDSMF2133IB EN 5.0
7.1.3 Process data signals for 8200 vector frequency inverters
General
Digital and analog input and output signals can be configured freely (see 8200 vector"
documentation: codes C0410, C0412, C0417 and C0421).
The change of code C0001 to 3 starts the preconfiguration of the process data words in the
controller (
¶ 46).
Process data telegram from drive
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6
Status word AIF−OUT.W1 AIF−OUT.W2
High byte Low byte High byte Low byte High byte Low byte
AIF−OUT.Wx see C0421.
